Accessoires Pour Freins Et Embrayages À Hystérésis
Courbes Couple/Courant
Les courbes de caractéristiques nominales similaires à celles affichées sont fournies par Magtrol. Des courbes d’étalonnage pour chaque frein peuvent être fournies, mais ceci doit être spécifié au moment de la commande et nécessitera des frais supplémentaires. Contactez Magtrol pour le prix et la livraison de freins complets avec courbes d’étalonnage.
Paliers
Les ensembles de paliers sont disponibles pour toutes les unités de frein et d’embrayage à l’exception du HB-840, HB-3500 et HB-3500M.
Pour les dessins de dimension détaillées, cliquez sur le lien souligné du modèle. Un document PDF s’ouvrira dans une nouvelle fenêtre.
(Adobe Acrobat Reader 7.0, ou version ultérieure est nécessaire.) Toutes les autres dimensions peuvent être trouvés dans les fiches techniques correspondantes.
Paliers | Adaptés aux freins/embrayages selon modèles (HB) | Adaptés aux freins/embrayages selon modèles (MHB) | Adaptés aux freins/embrayages selon modèles (HPM/HPMC) | Adaptés aux freins/embrayages selon modèles (HCS) | Adaptés aux freins/embrayages selon modèles (HCF) |
---|
4700 | HB-10M-2 | MHB-10M-2 | | | |
4702 | HB-8 | MHB-10.5 | HPM-8 HPMC-8 | | |
4703 | HB-16 | | HPM-16 HPMC-16 | | |
4704 | HB-20M | MHB-20M | | | |
4705 | HB-32 HB-50 | MHB-38 MHB -50 | HPM-32 HPMC-32 | | |
4706 | HB-50M-2 | MHB-50M-2 | | | |
4711 | HB-140 | MHB-140 | HPM-120 HPMC-120 | | |
4714 | HB-250 MHB-250 | | HPM-210 HPMC-210 | | |
4717 | HB-450 | MHB-450 | | | |
4720 | HB-750, | MHB-750 | | | |
4722 | HB-1750 | MHB-1760 | | | |
4723 | HB-3M-2 | MHB-3M-2 | | | |
4724 | | | | | HCF-32M |
4725 | | | | | HCF-120M |
4729 | | | | | HCF-16M |
4736 | HB-2.5 | MHB-2.5 | HPM-2.5 HPMC-2.5 | | |
4742 | | | | HCS-8 | |
4744 | | | | HCS-16 | |
4753 | | | | HCS-32 | |
4755 | | | | HCS-120 | |
4759 | | | | HCS-420 | |
4760 | | | | HCS-210 | |
4830 | | | | | HCF-250M |
4858 | HB-750M-2 | MHB-750M-2 | | | |
4864 | HB-140M-2 | MHB-140M-2 | | | |
4865 | HB-250M-2 | MHB-250M-2 | | | |
4866 | HB-450M-2 | MHB-450M-2 | | | |
4867 | HB-1750M-2 | MHB-1750M-2 | | | |
