CHB Series Base Mounted Hysteresis Brakes

CHB Series Base Mounted Hysteresis Brakes

Product Description

Sorry! Diese Seite ist auf Deutsch noch nicht verfügbar. Sie können jedoch diese Seite auf Englisch aufsuchen.

Pure Hysteresis Brakes produce torque strictly through a magnetic air gap without the use of magnetic particles or friction components. This method of braking provides far superior operating characteristics (smoother torque, longer life, superior repeatability, high degree of controllability, and less maintenance and down time) which make them the preferred choice for precise tension control during the processing of nearly any material, web or strand.

Specifications and Drawings

For complete technical specifications and a general dimension drawing, download the data sheet. For detailed dimension drawings. Click on the PDF icon in the table below and a PDF document will open in a new window. (Adobe Acrobat Reader 7.0, or later, is required.)

Hysteresis Brake ModelMinimum Torque at Rated Current (N·m)Rated Current (mA)Maximum Speed (rpm)Kinetic Power* - 5 Minutes (W)Kinetic Power* - Continuous (W)Downloads
CHB-11.0025312,00030075pdf | curve
CHB-1.51.7527010,000450110pdf | curve
CHB-33.204428,000670160pdf | curve
CHB-55.003837,0001,000200pdf | curve
CHB-66.006006,0001,340300pdf
CHB-1212.365006,0001,200350pdf | curve
CHB-2424.721,0006,0002,400600pdf | curve

*Kinetic power ratings are maximum values based on limiting coil and/or bearing temperature to approximately 100 ºC, and should not be exceeded. Actual values in service may vary ±50% depending on mounting, ventilation, ambient temperature, etc.
