Magtrol

	AHB Series Compressed-air-cooled Hysteresis Brakes • Ideal for low-torque/high-speed applications with exceptional power ratings • Excellent heat dissipation • Conveniently base mounted
• Combine with other Magtrol motor testing/torque measurement equipment to create a simple and cost-effective test bench

WB 23 High-speed Eddy-current Dynamometer
• Torque: 80 mNm
• Speed: up to 100,000 rpm

Micro Dyne
Complete out-of-the-box test system designed specifically for miniature/micro motors

Motor test equipment includes hysteresis, Eddy-current and magnetic powder dynamometers, controllers, power analyzers and software used to test the torque, speed and power of electric, pneumatic and hydraulic motors, gas engines and pumps. Application examples		Load-force-weight systems are comprised of load measuring pins, sensors/transducers and load monitoring electronics in order to provide safety, control and overload protection for cranes, hoists, winches and other heavy lifting equipment. Application examples
Torque transducers and sensors provide extremely accurate torque and speed measurement in motors, gears, pumps, clutches and valves over a very broad range, with high noise immunity. Application examples		Hysteresis brakes and clutches provide precise tension/torque control in many types of machinery, including textile, coil winding, EDM, wire & fiber optic cable, printing and packaging. Application examples
Rotary transmitters are used for signal transmission of transducers on a rotating part to a stationary system. Common applications include thermocouples and strain gauges. Application examples		Displacement transducers provide contactless measurement of absolute piston position in hydraulic and pneumatic cylinders and other applications. Application examples
Let Magtrol test your small AC and DC motors in our state-of-the-art motor testing lab. And, for U.S. customers, Magtrol offers dynamometers, controllers, power analyzers and motor fixtures for rent.		Magtrol’s engineering team can design a complete PC-based system or modular test bench for your motor test application. Each CMTS comes fully equipped & pre-assembled with your choice of component options.
